What’s New in Component Description Format

This topic provides a high-level overview of the new features in the IC23.1 release.

IC23.1 Base

UI Improvements in the Edit CDF Form

Earlier, the Component Parameter tab on the Edit CDF form supported the yes, no, and don't use values for the Store Default field. The tab also had the Parse as CEL and Parse as Number fields that allowed using different combinations for evaluation of parameter values.

Now, the Component Parameter tab has been enhanced with the following improvements:

• The Store Default field now supports only the yes and no values. The don't use value has been removed.
• The Parse As CEL and Parse As Number fields have been consolidated into a single list, Evaluation Mode, which lets you select pre-defined combinations for evaluation of parameter values.
• The fields in the Component Parameter tab now have tooltips that simplify specifying parameter values.
• The parsing of double quotes (") in choices for radio and cyclic type of parameters to CSV format has been enhanced.
