minFillToFillSpacing

Sets the minimum required distance, in user units, between metal fill geometries on a layer.

minFillToFillSpacing constraints have a Value that represents the minimum required distance, in user units, between metal fill geometries.

This example sets the minimum spacing between metal fill geometries to 2.0 user units on Metal1.

Format	Example
Tcl	set_layer_constraint -constraint minFillToFillSpacing \ -layer Metal1 -Value 2.0
LEF	PROPERTY LEF58_FILLTOFILLSPACING "FILLTOFILLSPACING 2.0 ;" ;
