What’s New in Virtuoso Design Rule Driven Editing

This topic provides a high-level overview of the new features in the IC23.1 release.

IC23.1 ISR2

Perform In-Design DRC Verification in Virtuoso Studio

You can now use the new DRC Options and Signoff Fill Signoff Fill forms to perform In-Design DRC verification in Virtuoso Studio. This enables you to perform DRC verification without breaking the design workflow.

minNeighborVoltageSpacing (One layer)

(Virtuoso Layout Suite EXL and higher tiers) Specifies the spacing based on a neighboring shape that meets the delta voltage condition.

minNeighborVoltageSpacing (Two layers)

(Virtuoso Layout Suite EXL and higher tiers)  Specifies the spacing between two shapes, which meets the delta voltage condition based on a neighboring shape.
