oaDefault45RouteGridPitch

Specifies the default 45 degree (right diagonal) route grid pitch for all layers and applies only to layers that do not have the 45RouteGridPitch constraint set.

oaDefault45RouteGridPitch Quick Reference

Value Types

oaDefault45RouteGridPitch constraints have a Value that represents the default 45 route grid pitch in user units.

Examples

set_constraint -constraint oaDefault45RouteGridPitch \
 -Value f_pitch

routingGrids(
( rightDiagPitch f_pitch )
)

Illustration of the example for oaDefault135RouteGridPitch constraint

Related Topics

Routing Constraints
