You can define the lower and upper tolerance values for input and input ground voltages in the Tolerance section of the Isolation category on the In-Design tab of the Power Manager Setup form.
The default value of the lower limit of the input power voltage and input ground voltage is -0.10. It should be less than or equal to 0. The default value of the upper limit of the input power voltage and input ground voltage is 0.10. It should be greater than or equal to 0.
