What’s New in Virtuoso Custom Design Migrate

IC23.1 ISR2

Defining the Path of the Schematic Design Inventory File

You can now define the path of the schematic design inventory file using the designInventoryPath argument in the schematic mapping configuration file. The default value of designInventoryPath is nil. The default path of the schematic design inventory file is "./ SCHMAP_CONFIG/SchDesignInventory.il".

IC23.1 ISR1

Wildcard Support for Cell Name in the Mapping File

You can now use wildcard characters for the cell name in the Schematic Migration mapping file.

New Options Supported in Mapping Configuration File

The schematic mapping configuration file now supports several new options. Refer to the user guide for the full list of supported options.

New SKILL APIs

You can use the following new SKILL APIs to control the Custom Design Migration Solution:

• schMapGetOption: Returns the value that is internally registered to the provided argument of the Schematic Migration configuration file.
• schMapLoadConfig: Loads the configuration file for Schematic Migration.
• schMapSaveConfig: Creates a configuration file with the arguments used in Schematic Migration that have values that differ from the default.
• schMapSetOption: Assigns values to the arguments of the Schematic Migration configuration file.

IC23.1 Base

Introducing the Virtuoso Custom Design Migration Solution

Virtuoso® Custom Design Migration is a new design migration solution that enables you to quickly port your designs from one technology to another.
Virtuoso Custom Design Migration includes the Virtuoso Custom Schematic Design Migration Solution, which provides automated design migration for single and multiple cells from the same library or different libraries. It has the following general features:

• Instances are placed and wired similarly to the original structure
• CDF parameters are updated and follow the callback order
• Support for configurations for symbol and pin placement
• Support for syntax to define the parameter values on the target design
• Utilities to update the device mapping file
• Results browser for debugging the migrated design
