Minority Charges And Capacitances

The transit time consists of two components:

Low current densities

The transit time reads:

The respective forward minority charge is given by:

Medium and high current densities

The total increase in the (forward) transit time is given by:

The critical current I_CKis described by the same voltage dependence as for HICUM/L2.:
