Gate Leak Currents

This section describes the parameters and equations for gate leak currents.

Instance Parameters

Parameter	Description
`Aforward`	Forward gate leakage current coefficient. Default value is `0.0`.
`Areverse`	Reverse gate leakage current coefficient. Default value is `0.0`.

If Aforward and Areverse are both 0.0, gate leak current is also 0.0.

Model Parameters

Parameter	Description
`Bforward`	Forward gate leakage current coefficient in `pow()`. Default value is `0.0`.
`Breverse`	Reverse gate leakage current coefficient in `pow()`. Default value is `0.0`.
`Cforward`	Forward gate leakage current coefficient in `exp()`. Default value is `0.0`.
`Creverse`	Reverse gate leakage current coefficient in `exp()`. Default value is `0.0`.
`Tcc`	Gate leakage current temperature coefficient. Default value is `0.0`.

Leak current between Gate and Drain

If Vgd>0

(-232)

If Vgd<0

(-233)

If Vgd=0

Igd=0.0

Leak current between Gate and Source

If IgcModel=0 and Igbmodel=0,
If Vgs>0

(-234)

If Vgs<0

(-235)

If Vgs=0

Igs=0.0

Otherwise,
Igc
If IgcModel=0 and Igbmodel=0, the above equations apply.
Otherwise, the following equations apply.
Igc=Igcs+Igcd

(-236)

For Igcmod=1

(-237)

For Igcmod=2

(-238)

(-239)

(-240)

Then

(-241)

(-242)

Igs and Igd

Igs represents the gate tunneling current between the gate and source diffusion region, while Igd represents the gate tunneling current between the gate and the drain diffusion region.

(-243)
