Level-2 Model
The level-2 diode model is used to model the Fowler-Nordheim tunneling current in thin insulators, such as silicon dioxide, commonly seen in nonvolatile memory. The peripheral diode is not supported for the level-2 model. If perim is specified, it is ignored.
DC Current
Linear Capacitance
Scaling Effects
The following are the Spectre scaling effects:
- if, ir, and cd are multiplied by area and m.
- rs is divided by area and m.
- If area is not specified and l and w are specified, area is calculated from l and w as follows:
Otherwise, area defaults to 1.
